Dynatron Q10 Cooling Fan/Heatsink

Description

This item is brand-new, factory sealed.

Q10
Recommend for Intel 12th Generation, Intel Core i9 Processors, Socket FCLGA 1700, Aluminum Radial fin Heat Sink with Copper Core Inserted, Active Cooler for 2U Server Up, Support 125 Watts CPU Base Power and Up to 140 Watts CPU Turbo Power.
Turbo Power is measured at 30^oC.CPU Support
IntelCPU Socket
LGA 1700Solution
2U Server and UpMaterial
Aluminum Radial fin Heat Sink with Copper Core InsertedFan Dimension
77 CM Plastic Fan with 4-Pin PWM Connector, 5500RPMSpeed
At Duty Cycle 0-20%: 1000 RPM
At Duty Cycle 50%: 2600 RPM
At Duty Cycle 100%: 5500 RPMBearing
Double BallRated Voltage
12VPower
At Duty Cycle 0-20%: 0.54 W
At Duty Cycle 50%: 1.68 W
At Duty Cycle 100%: 9.0 WAir Flow
At Duty Cycle 0-20%: 8.36 CFM
At Duty Cycle 50%: 25.53 CFM
At Duty Cycle 100%: 53.9 CFMNoise Level
At Duty Cycle 0-20%: 20.6 dBA
At Duty Cycle 50%: 35.1 dBA
At Duty Cycle 100%: 51.4 dBAStatic Pressure
At Duty Cycle 0-20%: 0.240 mm-H2O
At Duty Cycle 50%: 2.61.250 mm-H2O
At Duty Cycle 100%: 7.60 mm-H2OLead Wire Pin Out
Pin1-Black (-)
Pin2-Yellow (+)
Pin3-Green (Techometer/Signal output)
Pin4-Blue (PWM)Item Dimension (L”xW”xH”)
6 x 5 x 4
Weight
1.11 lbs
Warranty Information
1 Year

Features

Application/Usage:

Processor
CPU
Server

Features:
Dissipates the Heat
Compatibility:

• Intel Core i9 Processors
• Intel Core 12th -15th Gen
