Description
This item is brand-new, factory sealed.
* Dispersion: 100 x 50
* Dimensions: 7.5″x4.5″, 191mm x 114mm
* Cut-out: 6.7″ x 3.4″, 170mm x 86mm
* Depth: 4.5″, 114.3mm
* Weight: 2lbs, 909g
Replacement driver: APT:50
* Throat Size 1-in , 25.4mm
* Nominal Impedance: 8 ohms
* Power Rating: 35W at 3.5kHz
* Free Air Resonace 2.1kHz
* Usable Frequency Range 3.5Hz-20kHz
* Sensitivity: 104.7dB (1W/1m across 3.5kHz-20kHz)
* Magnet Weight 7.75oz, 0.22kg
* Voice Coil Diameter 1-in / 25.4mm
* THIELE & SMALL PARAMETERS
* DC Resistance (Re) 6.3
* Coil Inductance (Le) 1.5mH
* MOUNTING INFO
* Overall Diameter 2.75-in , 70mm
* Mounting Holes Diameter –
* Mounting Holes B.C.D. –
* Mounting Thread Use Apt Horn or Adaptor
* Depth 2.53-in , 64.3mm
* Weight 1.65 lbs, 0.75 kg
MATERIALS OF CONSTRUCTION
* Diaphragm Material Phenolic
* Magnet Composition Ferrite [Single]
Features
Country of Origin:
United States
