Icy Dock CP115 Drive Enclosure U.2, PCI Express NVMe 4.0 x4 – PCI Express 4.0 x4 Host Interface Internal – Black (mb111vp-b)

Description

This item is brand-new, factory sealed.

ExpressSlot Elite MB111VP-B
Removable 2.5″ U.2/U.3 NVMe SSD (7mm) to PCIe 4.0 x4 Mobile Rack Enclosure for PCIe Expansion Slot
Meet the ExpressSlot Elite MB111VP-B, a rugged and removable U.2/U.3 NVMe SSD enclosure designed to fit into a PCIe slot, supporting U.2/U.3 NVMe SSDs up to a height of 7mm. With the ability to fit into a single PCIe x4 expansion slot, this innovative drive mobile rack allows for easy removal of U.2/U.3 NVMe SSDs from the PCIe slot while minimizing the clutter from data and power cables.
Drive Swapping Made Simple
Say goodbye to complex drive-swapping procedures with the ExpressSlot Elite MB111VP-B. Equipped with a removable drive tray and supporting hot-plug functionality for U.2/U.3 NVMe drives, the MB111VP-B allows you to effortlessly add or remove drives in seconds without needing to power down or open the case. Furthermore, the SFF-8639 connector is rated for 10,000 insertion/removal cycles, allowing for longer-term usage with the system. *See FAQ for Hot-plug support.
Unleash PCIe Storage Potential
Unlock the full potential of your desktop computers storage capabilities with the ExpressSlot Elite MB111VP-B by utilizing your unused PCIe expansion slots. This storage solution allows adding a U.2/U.3 NVMe drive to your system, effectively exceeding your computers usual drive limitations. In addition, with the PCIe interface, you can take advantage of fast transfer speeds of up to 64Gbps.
Designed to fit the PCIe x4 card slot, the MB111VP-B is also compatible with PCIe x8 and x16 full-length PCIe slots, providing you with added flexibility and versatility.Color :
BlackSupport Drive Size :
2.5″ (supports only 7mm height U.2/U.3 SSDs)Compatible Drive Type :
U.2/U.3Number of Drives :
1Drive Bay :
1 x FHHL PCIe expansion slotHost Interface :
PCIe 4.0 x4Power Input :
via PCIe gold fingerTransfer Rate :
Up to 64GbpsDrive Cooling :
Metal heat dispersion with passive coolingStructure / Material :
Metal with partial ABS plasticHot-Plug :
YesDrive Activity LED Indication :
Drive power : solid green, Drive access : flashing greenPackage Contents :
Device, user manual, screwsSFF-8639 Connector Insertion Rate :
10,000Humidity :
5% to 65% RHOperating Temperature :
0^oC to 60^oC (32^oF to 140^oF)Storage Temperature :
-35^oC to 70^oC (-31^oF to 158^oF)Compliance :
CE, RoHS, REACHItem Dimension (L inchxW inchxH inch)
16 x 12 x 14
Weight
20.00 lb
Warranty Information
3 years

Features

Package Contents:

• U.2 NVMe SSD to PCIe 4.0 x4 Mobile Rack for PCIe Expansion Slot
• User Manual
• Screws
