Description
This item is brand-new, factory sealed.
Intel CPU BX8071512400F Core i5-12400F BOX 6Cores/12Threads 2.5GHz 18M S1700 RetailEssentials
Product Collection
12th Generation Intel Core i5 Processors
Code Name
Products formerly Alder Lake
Vertical Segment
Desktop
Processor Number
i5-12400F
Lithography
Intel 7
Use Conditions
PC/Client/TabletCPU Specifications
Total Cores
6
Number of Performance-cores
6
Number of Efficient-cores
0
Total Threads
12
Max Turbo Frequency
4.40 GHz
Performance-core Max Turbo Frequency
4.40 GHz
Performance-core Base Frequency
2.50 GHz
Cache
18 MB Intel Smart Cache
Total L2 Cache
7.5 MB
Processor Base Power
65 W
Maximum Turbo Power
117 WSupplemental Information
Embedded Options Available
NoMemory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max Number of Memory Channels
2
Max Memory Bandwidth
76.8 GB/sExpansion Options
Direct Media Interface (DMI) Revision
4.0
Max Number of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations
Up to 1×16+4, 2×8+4
Max Number of PCI Express Lanes
20Package Specifications
Sockets Supported
FCLGA1700
Max CPU Configuration
1
Thermal Solution Specification
PCG 2020C
TJUNCTION
100oC
Package Size
45.0 mm x 37.5 mmAdvanced Technologies
Intel Gaussian and Neural Accelerator
3.0
Intel Thread Director
No
Intel Deep Learning Boost (Intel DL Boost)
Yes
Intel Optane Memory Supported
Yes
Intel Speed Shift Technology
Yes
Intel Turbo Boost Max Technology 3.0
No
Intel Turbo Boost Technology
2.0
Intel Hyper-Threading Technology
Yes
Intel 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States
Yes
Enhanced Intel SpeedStep Technology
Yes
Thermal Monitoring Technologies
Yes
Intel Volume Management Device (VMD)
YesSecurity and Reliability
Intel Standard Manageability (ISM)
Yes
Intel Control-Flow Enforcement Technology
Yes
Intel AES New Instructions
Yes
Secure Key
Yes
Intel OS Guard
Yes
Execute Disable Bit
Yes
Intel Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel VT-x with Extended Page Tables (EPT)
YesItem Dimension (L”xW”xH”)
5 x 3 x 4
Weight
1 lb
Warranty Information
3-year limited
Specs
| Physical Characteristics | |
| Width | 1.8″ |
| Depth | 1.8″ |
| Display & Graphics | |
| Integrated Graphics | No |
| General Information | |
| Brand Name | Intel |
| Package Type | Retail |
| Marketing Information | Processors Intel designs advanced, high-performance processors for every usage, including enterprise-scale servers, IoT devices, laptops, desktops, workstations, and mobile devices. To find information, specifications, downloads and support for each processor, start by selecting a Processor family. |
| Product Type | Processor |
| Product Name | Core i5 Hexa-core i5-12400F 2.50 GHz Desktop |
| Manufacturer | Intel Corporation |
| Manufacturer Part Number | BX8071512400F |
| Product Model | i5-12400F |
| Product Line | Core i5 |
| Technical Information | |
| Processor Core | Hexa-core (6 Core) |
| Overclocking Speed | 4.40 GHz |
| Processor Manufacturer | Intel |
| L3 Cache | 18 MB |
| Processor Threads | 12 |
| Processor Socket | Socket LGA-1700 |
| Clock Speed | 2.50 GHz |
| 64-bit Processing | Yes |
| Processor Generation | 12th Gen |
| Environmental Conditions | |
| Thermal Specification | 212°F (100°C) |
