Description
This item is brand-new, factory sealed.
Multi-Zone Lighting Controller – 4-Independent Zones
Shadow-Caster’s “Zone Controller” allows for individual or simultaneous control of up to four separate lighting zones. Co-developed with WetSounds, the SCM-ZC gives the user the ability to quickly change the color and brightness of their lights, and allows for the synchronization of lights with music. Shadow-Net technology allows for the control of any RGB color-changing lights. It also allows integration with multi-functional displays and other audio visual equipment. The zone controller is perfect for total control of all of the lighting on a boat, RV or other automobiles.
The Multi-Zone Lighting Controller, is the first of its kind on the market. Co-Developed with Wet Sounds® the “Zone Controller” is an LED lighting controller perfect for marine and terrestrial applications. It is fully waterproof and capable of controlling all RGB and Shadow-NET enabled lights. Shadow-NET is a proprietary protocol developed by Shadow-Caster Lighting to communicate lighting color information via an embedded CAN (Control Area Network) bus.
Shadow-Caster’s “Zone Controller” allows for individual or simultaneous control of up to four separate lighting zones. Quickly change color and brightness or synchronize the lights to music. Shadow-Net technology allows for control of lighting through integration into multi-functional displays and other audio visual equipment. The zone controller is perfect for total control of all of the lighting on a boat or yacht.
Small, sleek, and user friendly, the Zone Controller installs in a standard 3 inch gauge opening and includes a wiring harness and mounting hardware. The interface is backlit and uses tactile response switches. The Zone controller is the only waterproof, multi-functional RGB LED controller on the market today.
Specifications:
- Size: 3.625″ outside diameter X 0.5″ Height (92 x 13mm)
- UV stabilized polycarbonate cover with stainless steel bezel
- Machined aluminum rear housing
- IP65 controller and connector with 18″ harness
- Supports up to 500W of LED lights
- Operating voltage: 10 – 30 volts DC
- 16 Illuminated silicone buttons
- 4 Independent zones
- Shadow-Net Enabled
- 1-Year Warranty
- Made in the USA
