Description
This item is brand-new, factory sealed.
*Continuous power rating: 600W *Sensitivity: 96dB *Voice coil diameter: 2.5-in *Nominal diameter: 305mm / 12-in *Power rating: 300W *Continuous power rating: 600W *EIA power rating: 450W *Rated impedance: 8 Ohms; *Sensitivity: 96dB *Frequency range: 50-3000Hz *Chassis type: Pressed steel *Magnet type: Ferrite *Magnet weight: 1.4kg / 50oz *Voice coil diameter: 64mm / 2.5-in *Voice coil material: Edgewound copper *Former material: Polyimide *Cone material: Kevlar loaded paper *Surround material: Cloth-sealed *Suspension: Single *Gap height (Hg): 8mm / 0.31-in *VC winding height (Hvc): 14.5mm / 0.57-in
Parameters *Sd: 530.93cm squared / 82.29-in squared *Fs: 52.60Hz *Mms: 54.04g / 1.91oz *Qms: 3.513 *Qes: 0.368 *Qts: 0.333 *Re: 6.42 Ohms; *Vas: 67.71l / 2.39ft cubed *BI: 17.66Tm *Cms: 0.17mm/N *Rms: 5.08kg/s *Le (at 1kHz): 1.32mH *Xmax: 5.25mm / 0.21-in
Mounting Information *Overall diameter: 309mm / 12.17-in *Overall depth: 139mm / 5.5-in *Cut-out diameter: 283mm / 11.14-in *Mounting hole dimensions: 7.9mm / 0.31-in Diameter *Number of mounting holes: 4 *Mounting hole PCD: 297mm / 11.69-in *Unit weight: 4.4kg / 9.7lb
Packed Dimensions & Weight *Single pack size W x D x H: 330mm x 330mm x 150mm / 13-in x 13-in x 5.9-in *Single pack weight: 5.0kg / 11.0lb *Multi pack qty: 60 *Multi pack size W x D x H: 1080mm x 980mm x 880mm / 42.5-in x 38.6-in x 34.6-in *Multi pack weight: 290kg / 638lb
Frequency Response and Impedance Curves [Each]
